Angle Shearing Machine
Standard Supply:
• Main drive Motor
• Electric control panel with INCH & SINGLE CYCLE AUTO OPERATION
• Stroke adjustment rod with Limit Switch
• Punch & Die Adaptor
Application
• Angle Cutting.
Specifications:
Capacity
120 Ton 220 Ton
Angle Size 90 x 90 x 10MM 150 x 150 x 16MM
Stroke of Cylinder 50 MM 50 MM
Oil Tank Capacity 160 Ltrs 160 Ltrs
Type of Operation Single Cut Type Single Cut Type
Motor Speed 7.5 H P (1440 RPM) 15 / 6 SPM
Working Pressure 220 Kg 220 Kg
Speed : Downward & Upward 15 /6 SPM 15 / 6 SPM
Working Height 850 MM 850 MM
Net Weight 1500 Kgs 2000 Kgs
